Organic Light-Emitting Diode
Full view angle, Fast response, High contrast, Simple structure, Good performance under low-temperature.
| P/N | Size | Packaging and Interconnect | Display Mode | Color | Resolution | Active Area (mm) | Thickness (mm) | Outline | Parallel | Serial | I2C |
|---|---|---|---|---|---|---|---|---|---|---|---|
| TPO0093-W | 0.48" | COG with Flex for Soldering | Mono | W | 72*32 | 11.21*4.97 | 1.2 | 14.90*11.29 | Y | ||
| TPO1024-W | 0.66" | COG with Flex for Soldering | Mono | W | 64*48 | 13.42*10.06 | 1.25 | 18.46*18.10 | Y | Y | Y |
| TPO1032-W | 0.69'' | COG with Flex for Soldering | Mono | W | 96*16 | 17.26*3.18 | 1.2 | 26.30*8.00 | Y | ||
| TPO0092-W | 0.84" | COG with Flex for Soldering | Mono | W | 96*18 | 21.10*3.58 | 1.6 | 29.40*8.40 | Y | Y | |
| TPO1029-W | 0.9" | COG with Flex for Soldering | Mono | W | 128*36 | 21.73*6.10 | 1.2 | 25.38*10.00 | Y | ||
| TPO1031-W | 0.91" | COG with Flex for ZIF | Mono | W | 128*32 | 22.38*5.58 | 1.2 | 30.00*11.5 | Y | ||
| TPO1010-W | 0.95" | COG with Flex for Soldering | Mono | W | 96*64 | 19.95*13.42 | 1.45 | 24.90*20.53 | Y | Y | Y |
| TPO0083-B | 0.96'' | COG with Flex for Soldering | Mono | B | 128*64 | 21.74*11.17 | 1.45 | 26.70*19.26 | Y | Y | Y |
| TPO0085-B | 0.96'' | COG with Flex for Soldering | Mono | B | 128*64 | 21.74*11.17 | 1.45 | 26.70*19.26 | Y | ||
| TPO1023-W | 0.96" | COG with Flex for Soldering | Mono | W | 128*64 | 21.74*11.17 | 0.96 | 26.70*19.26 | Y | Y | Y |
| TPO1027-W | 0.96" | COG with Flex for Soldering | Mono | W | 64*128 | 21.74*10.86 | 1.2 | 28.00*15.00 | Y | Y | Y |
| TPO1007-Y | 1.1" | COG with Flex for ZIF | Mono | Y | 96*96 | 19.655*19.655 | 1.45 | 25.49*29.10 | Y | Y | Y |
| TPO1007-W | 1.1" | COG with Flex for ZIF | Mono | W | 96*96 | 19.655*19.655 | 1.45 | 25.49*29.10 | Y | Y | Y |
| TPO1007-R | 1.1" | COG with Flex for ZIF | Mono | R | 96*96 | 19.655*19.655 | 1.45 | 25.49*29.10 | Y | Y | Y |
| TPO1003-L3 | 1.1" | COG with Flex for Soldering | Full color | - | 96*96 | 19.85*19.85 | 1.45 | 25.49*29.10 | Y | Y | |
| TPO1025-W | 1.12" | COG with Flex for BTB | Mono | W | 128*128 | 20.14*20.14 | 1.25 | 27.00*30.10 | Y | Y | Y |
| TPO1028-W | 1.13" | COG with Flex for Soldering | Mono | W | 128*128 | 28.80*28.80 | 1.45 | 37.62*41.31 | Y | Y | Y |
| TPO1026-W | 1.3" | COG with Flex for Soldering | Mono | W | 128*64 | 29.42*14.7 | 1.45 | 34.50*23.00 | Y | Y | Y |
| TPO1033-W | 1.32" | COG with Flex for ZIF | Grayscale | W | 128*96 | 26.86*20.14 | 1.6 | 32.60*28.30 | Y | ||
| TPO1009-W | 1.50" | COG with Flex for ZIF | Mono | W | 128*128 | 26.86*26.86 | 1.45 | 33.90*37.30 | Y | Y | Y |
| TPO1009-Y | 1.50" | COG with Flex for ZIF | Mono | Y | 128*128 | 26.86*26.86 | 1.45 | 33.90*37.30 | Y | Y | Y |
| TPO1014-W | 1.50" | COG with Flex for ZIF | Mono | W | 160*160 | 26.86*26.86 | 1.45 | 33.90*37.30 | Y | Y | Y |
| TPO0087-Y | 1.54'' | COG with Flex for ZIF | Mono | Y | 128*64 | 35.04*17.51 | 1.45 | 42.04*27.22 | Y | Y | Y |
| TPO0087-W | 1.54'' | COG with Flex for ZIF | Mono | W | 128*64 | 35.04*17.51 | 1.45 | 42.04*27.22 | Y | Y | Y |
| TPO0088-Y | 2.05'' | COG with Flex for Soldering | Mono | Y | 128*32 | 50.54*12.62 | 1.45 | 55.60*21.80 | Y | Y | Y |
| TPO0088-W | 2.05'' | COG with Flex for Soldering | Mono | W | 128*32 | 50.54*12.62 | 1.45 | 55.60*21.80 | Y | Y | Y |
| TPO0065-R | 2.7" | COF with Flex for ZIF | Grayscale | R | 256*64 | 66.54*16.62 | 1.45 | 82.00*25.50 | Y | Y | |
| TPO0065-G | 2.7" | COF with Flex for ZIF | Grayscale | G | 256*64 | 66.54*16.62 | 1.45 | 82.00*25.50 | Y | Y | |
| TPO0065-B | 2.7" | COF with Flex for ZIF | Grayscale | B | 256*64 | 66.54*16.62 | 1.45 | 82.00*25.50 | Y | Y | |
| TPO0065-Y | 2.7" | COF with Flex for ZIF | Grayscale | Y | 256*64 | 66.54*16.62 | 1.45 | 82.00*25.50 | Y | Y | |
| TPO0065-W | 2.7" | COF with Flex for ZIF | Grayscale | W | 256*64 | 66.54*16.62 | 1.45 | 82.00*25.50 | Y | Y | |
| TPO1020-W | 2.8" | COG with Flex for ZIF | Grayscale | W | 256*64 | 17.26*69.10 | 2 | 28.5*80.5 | Y | Y | Y |
| TPO1018-Y | 3.08" | COG with Flex for ZIF | Mono | Y | 20*2 | 77.30*11.85 | 2 | 89.45*19.85 | Y | Y | Y |
| TAO90020013V0 | 1.3" | COG with Flex for ZIF | Full color | - | 360*360 | φ32.94 | 0.548 | 35.34*36.84 | MIPI 1 lane/2 lane | ||
